imread
Read image from graphics file.
📝Syntax
A = imread(filename)
[A, map] = imread(filename)
[A, map, transparency] = imread(filename)
📥Input Arguments
Parameter Description
filename a row vector characters or scalar string: name of graphics file.
📤Output Arguments
Parameter Description
A Image data: array.
map Colormap: m-by-3 matrix.
transparency Transparency information: matrix.
📄Description

imread reads the image data from the given file into a matrix.

The file type is detected from its signature. The extension is used as a fallback for textual or ambiguous formats. For animated GIF files, the first composited frame is returned; for TIFF files, the first page is returned.

Indexed images return an M-by-N uint8 matrix, a K-by-3 double colormap in [0, 1] and, when present, an M-by-N uint8 transparency matrix. RGB and RGBA images return an M-by-N-by-3 uint8 array; RGBA transparency is returned separately as the third output. Sixteen-bit grayscale PNG, TIFF and PGM images return an M-by-N uint16 matrix.

Format Access
BMP/DIB read
GIF read, first composited frame
JPEG/JFIF (JPG) read
TIFF read, first page
PCX read
PNG read
PBM read
PGM read
PPM read
WebP, TGA, PNM read
PSD, HDR/RGBE, PIC read only
💡Examples
f = figure();
filename = [tempname, '.webp'];
imwrite(rand(32, 32, 3), filename, 'Quality', 90);
img = imread(filename);
imagesc(img);
close(f);
Example illustration
WebP transparency, indexed PNG and 16-bit grayscale data.
source = rand(16, 16, 3);
alphaSource = rand(16, 16);
webpFile = [tempname, '.webp'];
png16File = [tempname, '.png'];
indexedFile = [tempname, '.png'];
imwrite(source, webpFile, 'Alpha', alphaSource);
imwrite(uint16(reshape(0:255, 16, 16) * 257), png16File);
indices = uint8([0 1; 1 0]);
palette = [1 0 0; 0 0 1];
imwrite(indices, palette, indexedFile);
[rgb, map, alpha] = imread(webpFile);
gray16 = imread(png16File);
[X, indexedMap, indexedAlpha] = imread(indexedFile);
🔗See Also
imagescimformats
🕔Version History
Version Description
1.0.0 initial version
1.13.0 pcx, tiff formats added
2.0.0 WebP and deterministic Qt-free codecs added
